Application : Suitable for general purpose air & water application in industries & irrigation.
Lining : Natural & Synthetic Rubber blend.
Cover : Natural Rubber with good ageing properties.
Reinforcement: Synthetic yarn with high level of retentivity.
Temp. Range : -40°C to + 80°C
Working Pressure : 12 bar
Safety Factor: 4 times working pressure



Application : Suitable for use in open cast mines & quarries for use in pneumatic air application.
Lining : Natural & Synthetic Rubber blend.
Cover : Natural Rubber with excellent ageing & abrasion resistance.
Reinforcement: Synthetic Yarn with high level ofretentivity.
Temp. Range : -40°C to + 80°C
Working Pressure : 14 to 18 bar
Safety Factor: 4 times working pressure



Application : Suitable for pneumatic tools in process industry & and any compressed air application.
Lining : Natural & Synthetic Rubber blend.
Cover : Natural Rubber with good ageing & abrasion resistance.
Reinforcement: Synthetic Yarn with high level of retentivity.
Temp. Range : -40°C to + 80°C
Working Pressure : 14 to 18 bar
Safety Factor: 4 times working pressure



Lining : Synthetic Rubber with excellent heat ageing properties.
Cover : Synthetic Rubber with excellent heat ageing & abrasion resistance.
Reinforcement: High tenacity cotton yarn.
Temp. Range : -40°C to + 160°C
Working Pressure : 7 bar
Safety Factor: 10 times working pressure

IS:10655 Type 2 / BS:5342 Type 1/1B:


Tube : EPDM synthetic rubber with heat resistant properties.
Lining : One high tensile steel brass coated wire braid.
Cover: Synthetic rubber weather, abrasion, ozone & aging resistant.
Temperature : upto 180 Deg C
Working Pressure : 10 bar
Safety Factor: 10 times working pressure

IS:10655 Type 3 / BS:5342 Type 2/2B:


Tube : EPDM synthetic rubber with heat resistant properties.
Lining : Two high tensile steel brass coated wire braid.
Cover: Synthetic rubber weather, abrasion, ozone & aging resistant.
Temperature : upto 235 Deg C
Working Pressure : 16 bar
Safety Factor: 10 times working pressure
